Enclosed Type SMPS Specification Sheet

PCB Name/ Description : ATS-512 R2.0 INPUT   Description Output AC Input Voltage 230V AC AC Input Voltage range 90V TO 270V AC AC Input frequency 50Hz to 60Hz Primary current protection NTC & Fuse AC Input Withstand Voltage Up To 350 V AC For 15 Min Inrush Current <15A OUTPUT   Description Single Output Normal DC O/P Voltage 5V ± 0.1V (Adjustable Up to 6V) Minimum Load Current 0 A Maximum Load Current 12A Maximum O/P Power 60W Ripple & Noise <150 mV Under and Over Voltage protection Feedback Loop Total O/P Regulation < 2% Short Circuit protection With auto recovery. Yes MECHANICAL   Description Output Dimensions 127mm X 76mm X 38mm I/P plug Type 2 Pin CPU Connector O/P plug Type 3 Pin CPU Connector Each For Positive & Negative ENVIRONMENT   Description Output Operating temp Upto 60 deg.C at full load
